Conductivity Meter P611 Series

Conductivity Meter P611 Series

Conductivity Meter P611 Series

Conductivity Meter P611 Series Features 1.Large screen LCD display, Blue back light Controllable. 2. With intelligent functions of time display, full automatic calibration, automatic power off, power-off protection, automatic calibration, a
Contact Now
Detailed Product Description

  Conductivity Meter P611 Series

Features

1.Large screen LCD display, Blue back light Controllable. 2. With intelligent functions of time display, full automatic calibration, automatic power off, power-off protection, automatic calibration, automatic or manual temperature compensation, automatic diagnosis and etc.
3. Undervoltage prompt and automatic power off can extend battery life.
4. Optional 5 kinds of PH buffer solution can make 1-3 points automatic calibration.
5. Can test PH value for ultrapure water, pure water and boiler water by adjusting equipotential point and special electrode.
6. Ability to store test result, cancel, view and print. Can store 1000 sets of data.
7. With waterproof portable suitcase and folding holder, the level of protection for outer layer is IP67.
8. Automatic identification of 12 kinds of PH standard buffer solution. There are USA, NIST and CH series of standard buffer solution for option. Custom solution calibration.
9. Automatic identification of 8 kinds of conductivity standard solution. There are USA and CH series of standard solution for option. Custom solution calibration.

Technical Parameters:





p613

p612

p611

Category

Product Name

Basic features and specifications

PH

Measuring range

(-2.00 ~ 19.99)pH

/

(-2.00 ~ 19.99)pH

Resolution

0.1/0.01 pH

/

0.1/0.01 pH

Accuracy

Meter:±0.01pH; Overall: ±0.02pH

/

Meter:±0.01pH; Overall: ±0.02pH

Input impendance

≥1×1012 Ω

/

≥1×1012 Ω

Stability

±0.01 pH/3h

/

±0.01 pH/3h

Temp. compensation range

(0 ~ 100)℃(automatic)

/

(0 ~ 100)℃(automatic)

ORP

Measuring range (mV/ORP/EH)

-1999mV ~ 0 ~ 1999mV



-1999mV ~ 0 ~ 1999mV

Resolution

1mV



1mV

Accuracy

:±0.1% FS



:±0.1% FS

Conductivity

Measuring range

Conductivity:(0.00~19.99)μS/cm (20.0~199.9)μS/cm (200~1999)μS/cm (2.00~19.99)mS/cm (20.0~199.9)mS/cm TDS: (0 ~ 100)g/L Salinity: (0 ~ 100)ppt Resistivity:(0 ~ 100)MΩ·cm

Conductivity:(0.00~19.99)μS/cm (20.0~199.9)μS/cm (200~1999)μS/cm (2.00~19.99)mS/cm (20.0~199.9)mS/cm TDS: (0 ~ 100)g/L Salinity: (0 ~ 100)ppt Resistivity:(0 ~ 100)MΩ·cm

/

Resolution

0.01/0.1/1μS/cm 0.01/0.1 mS/cm

0.01/0.1/1μS/cm 0.01/0.1 mS/cm

/

Accuracy

±1.0% FS, Overall:±1.5% FS

0.01/0.1/1μS/cm 0.01/0.1 mS/cm

/

Temp. compensation range

(0 ~ 50)℃(manual)

(0 ~ 50)℃(manual)

/

Electrode constant

0.1 / 1 / 10 cm-1

0.1 / 1 / 10 cm-1

/

Other Technical Parameters

Data storage

1000 groups

Power

Two AA batteries (1.5V x2)

Size and weight

 (360×270×76)mm/1.6Kg

Working Condition

Environment temperature

5 ~ 35 ℃(0.01grade)

Environmental humidity

≤85%





IP rating

IP57 Dustproof and waterproof
